Form cutters

Article no. CH-50052150

back to list
  • Spade step drill

    • This flat form drill is ground with a shear angle.
    • It is clear to see how the flute runs off centre at the side along the workpiece axis.
    • The reliefs on the circumference run exactly along the flute.
    • The form on the circumference can be freely defined.
    • This option demands item no. CH-50052150 (Form cutters).
  • Cone-shaped drill with dual cutting angle

    • Cone-shaped drill ground with dual shear angle.
    • The form on the circumference can be freely defined.
    • This option demands item no. CH-50052150 (Form cutters).
  • Christmas tree cutter

    • Christmas tree cutter with cam relief
    • This option demands item no. CH-50052150 (Form cutters).
  • End mill with a double radius tip

    • This option demands item no. CH-50052150 (Form cutters).
  • Milling cutters for turbine blades

    • This milling cutter is used to machine the basic body of turbine blades on aircraft.
    • The precision of the form is an a range of +/- 0.015 mm.
    • Before the form is ground with a tip wheel, it is first prepared with special machining as close as possible to the profile.
    • This option demands item no. CH-50052150 (Form cutters).
  • Double form cutter

    • This double form cutter has 4 flutes.
    • Some sections in the form must be sharp-edged. To do this the form divides into two groups of teeth intersecting.
    • This option demands item no. CH-50052150 (Form cutters).
  • Milling cutters with helical and roughing profiles

    • Milling cutters with helix, increasing/decreasing forms and roughing profiles.
    • The roughing profiles are made by the form and not with the cutter profile option.
    • This option demands item no. CH-50052150 (Form cutters).
  • Engraver cutting in the centre

    • This engraver has a straight cutting edge which is ground below the centre.
    • This option demands item no. CH-50052150 (Form cutters).
  • Watch case cutter

    • This PCB milling cutter has a straight cutting flute which is ground below the middle.
    • The forms are different for each tooth. The long tooth cuts below the middle.
    • This option demands item no. CH-50052150 (Form cutters).
  • O-ring cutter

    • O-ring cutter, straight fluted.
    • This option demands item no. CH-50052150 (Form cutters).
  • Dove tail cutter

    • Dove tail cutter, straight fluted.
    • This option demands item no. CH-50052150 (Form cutters).
